LP Gas Grill
ASSEMBLY INSTRUCTIONS
Step 10
Install the control knobs (13) onto the control panel of the
grill body (12) by gently pushing them onto the valve stem.
Control
Knob
Parts Used
2 pc 13
13
12
12 13
1. Secure the cart swivel upper rear panel
(11) to the cart left side panel (4) and cart
right side panel (5) with two screws (C).
Then install another 2 screws (C) into the
upper mounting holes of the left and right
side panels. These will secure the cart
swivel upper rear panel (11) when it is in
the closed position.
2. Rotate the cart swivel rear panel
upper (11) upwards until the two screws
(C) on the cart left and right side panels
snap into the two slots on the cart
swivel rear panel upper.
5
C
11
11
C
M6
Step Screw
Hardware Used
4 pc
Step 9
4
