Page 76

Compuprint 6314/6414 - User Manual

7 S

ERIAL

ORT

IRING

RS 232 serial port pin assignment (DB9 plug)

Pin number Signal

1 DCD
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 SRTS

Table 17 – RS232 serial port pin assignment
