L o a d i n g R i b b o n
Make sure the printer is configured to use a ribbon.
To load ribbon:
1. Open the cover.
2. Unlock the printhead by turning the retaining latch.
3. Lift printhead assembly using the printhead tab until the
assembly locks into place.
4. Push the deflector tab down.
5. Slide the extra ribbon core on the take-up reel as far as it will
go with the "This End Out" writing facing out. Use your empty
ribbon core as the take-up core. The take-up core only fits on
the take-up reel one way. (An extra take-up core is available
by ordering part number 117961.)
Printhead
Assembly
Deflector
Tab
3-2 Loading Ribbon
