Specifications A-1
S P E C I F I C AT I O N S
P r i n t e r S p e c i f i c a t i o n s
Height: 2.25 inches (57 mm)
Width: 4.25 inches (108 mm)
Length: 6.0 inches (152 mm)
Weight:
w/ battery & supply 1.41 lbs. (0.64 kg)
Shipping Weight: 3 lbs. (1.4 kg)
Power: 6.0V NiMH battery
Operating Limits:
Storage: 32
°
to 104
°
F (0
°
to 40
°
C)
-4
°
to 104
°
F (-20
°
to 40
°
C)
Operating Humidity:
Storage: 20% to 85% non-condensing
5% to 95% non-condensing
Printhead: 3 inches (76 mm) wide
203 dpi (8 dots per mm)
Printing
Method: Thermal Direct
Print
Speed: Up to 2.0 inches per second (for
standard receipts)
NOTE: The speed is dependent
on the application.
Supported Fonts
(Bitmap): Standard (normal and bold),
Large (normal), Reduced (normal
and bold), and Large Rotated.
Supported
Bar codes: Codabar, Code 39,
UCC/EAN – 128, UPC/EAN/JAN,
Interleaved 2 of 5, Code 128.
Memory: 32K SRAM
128K Flash
A
