1-4 Getting Started
Power ( P) Button
C h a r g i n g t h e B a t t e r y
The printer’s battery must be charged before using it.
The battery can be charged
♦ using the single or four-station charger. See
Appendix A, “Specifications” for part numbers.
♦ inside the printer using the plug-in charger for
select printers. However, not all printers allow the
battery to be charged inside the printer – see
Appendix A, “Specifications” for more information.
1. Plug the cable
into the socket
located on the
side of the
printer as
shown.
2. Insert the plug-
in charger into
an electrical
outlet.
Charging time is approximately 1.5 hours.
U s i n g t h e A C A d a p t e r
Some printers use an AC adapter, which
allows you to use the printer while it is
plugged into a wall outlet. Using the AC
adapter eliminates the need to charge the
battery, since the printer operates on AC
current instead.
1. Connect the plug to the AC adapter.
2. Plug the cable into the socket located
on the side of the printer.
3. Plug the AC adapter into an electrical
outlet.
Feed Button
Connects to printer
