2-2 Loading Supplies
3. Drop the supply into the well. Make sure the supply
unwinds from the bottom as shown.
4. Position the supply between the printhead guides.
5. Make sure 2-3 inches of supply extends past the
printhead.
6. Close the supply door.
7. Turn on the printer.
T e a r i n g S u p p l y
The printer’s supply door acts as a tear bar. Tear down
against the tear bar to remove receipts.
NOTE: Do not tear supply up against the printhead or
sideways, because the supply door may open.
Tear Bar
