1-8 Getting Started
Tab
A t t a c h i n g t h e B e l t C l i p
1. The printer comes with a belt clip.
2. Turn the printer over.
3. Attach the belt clip as shown. Insert the printer’s
round knob into the latch and pull up until it “clicks”
into place.
4. Attach the belt clip to your belt by looping the strap
around your belt and snapping it into place.
To remove:
1. Remove the belt
clip from your belt.
2. Remove the printer
from the belt clip
by squeezing the
tabs and pulling
the clip down.
Strap
