564 HO DancingFyre Burner
Installation Instructions
(sku: 96900114)
Page 2 of 11
17601661 — 9/22/11
© Travis Industries, Inc.
Andiron Clips
NOTE: Two andiron clips are included for those installations using andirons. See directions below to install.
Figure 1: Andiron Clips Installation
5/32 Hex
Wrench
11/32" Nutdriver
a
b
c
