Using HPI-B
System Management Interface Based on BBS HPI-B 2.0 (Centellis 4620/4440) User’s Guide (6806800P21D) 59
4.6.5 Failed Slot Restore Control
"Failed Slot Restore Control" control enables the user to initiate a re-discovery of the resource in
the slot and sets the ResourceFailed flag in RPT to false. The ResourceFailed flag in
the RPT Entry of slot resource is set to true if the discovery of the resource in the slot fails, or
the resource in the slot is in failed state. The ResourceFailed flag of the slot resource can be
set to false in any one of the following conditions:
1. Resource in failed state is removed using saHpiResourceFailedRemove().
2. If any of the resource is inserted into the failed slot.
An example application hpislotrestore can be used to set and get the new control "Failed
Slot Restore" state.
Table 4-19 Failed Slot Restore Control RDR
SaHpiRdrT Value Notes
RecordId
Assigned by HPI implementation.
RdrType SAHPI_CTRL_RDR
Entity
Entity path of the slot resource.
IsFru SAHPI_FALSE
RdrTypeUnion.CtrlRec.Num MOTHPI_CTRL_FAILED_SLOT_RESTORE
_NUM
RdrTypeUnion.CtrlRec.Type SAHPI_CTRL_TYPE_DIGITAL
RdrTypeUnion.CtrlRec.OutputType SAHPI_CTRL_GENERIC
RdrTypeUnion.CtrlRec.TypeUnion.
Digital.Default
SAHPI_CTRL_STATE_OFF
RdrTypeUnion.CtrlRec.DefaultMod
e.Mode
SAHPI_CTRL_MODE_MANUAL
RdrTypeUnion.CtrlRec.DefaultMod
e.ReadOnly
SAHPI_TRUE
RdrTypeUnion.CtrlRec.WriteOnly SAHPI_FALSE
RdrTypeUnion.CtrlRec.OEM
Assigned by HPI implementation.
RdrTypeUnion.CtrlRec.IdString MOTHPI_CTRL_FAILED_SLOT_RESTORE
_NAME
