Commands Execution
ViewCheck on ATCA-7470/7475 Installation and Use (6806800S49E) 78
4.5.1 Monitoring Hardware Device Status
InService Monitoring also periodically polls for various devices status on the blade. They are
 CPU Core temperature status
 Storage Device HDD Health Status
 Network Devices Counter Statistics
 Network Devices Error Statistics
Each of the above is identified by a unique Monitor ID. For more information about Monitor ID,
refer
Monitor ID on page 18 .
The default Poll Interval for monitoring each of the Monitor ID is set to 10 seconds. Commands
are provided to edit the default settings.
For more information on the commands provided for InService Monitoring, refer Monitoring
Commands on page 62 .
The following table provides list of monitor IDs and device instances for each of the monitors
being monitored on ATCA-7470/7475.
Table 4-29 Monitors
Monitor Description
Monitor
ID
Valid Device Instances Remarks
CPU Core
Temperatures 1000 Core 0 to Core 19 (0 to
15) Temperature of the 16 cores
available on ATCA- 7470 CPU and
20 cores available on ATCA-7475
CPU are monitored individually
and reported if crosses a Set
Threshold value.
HDD Health Status 1010 sda1 to sda8
sdb1 to sdb8 Monitors the health status of the
sda1 to sda8 partitions on the
HDD and reports.
Network Errors 1020 base1(70), base2(71),
fabric 1(73), fabric 2(74),
rtm1(147), Monitors the various error
counters for each of the Network
Device Instances and provides an
error counter exceeds the rate of
change.
