Chapter 3
ViewCheck on ATCA-7470/7475 Installation and Use (6806800S49E) 21
Installation of ViewCheck
3.1 Overview
This section explains the ViewCheck release modules and installation procedures to install and
run ViewCheck service on the Artesyn ATCA-7470/7475 blade.
ViewCheck service is released as an RPM image. BSF RPMs are also distributed along with
ViewCheck RPMs.
3.2 ViewCheck RPM Image
The ViewCheck RPM Image functionally comprises Diagnostics Framework, specific test cases,
and test suites. The ViewCheck RPM always uses same OS variant and compile time
environment based on the BBS release of the target blade. For ATCA-7470/7475 blades, the
ViewCheck RPM is created for PNE 4.x environment.
ViewCheck service RPM consists of:
 Diagnostics Core - Daemon
 Static Test Suite Configuration files for the specific blade
 Start/Stop scripts for Diagnostics Core
Using the following command, you can install the ViewCheck RPM Image:
rpm -iv --nodeps diagnostics-
_...atca7470.rpm
Using the following command, you can remove the ViewCheck RPM Image:
rpm -e diagnostics-_...atca7470.rpm
The following table provides details of the files that are created on the blade once the
ViewCheck RPM is installed.
Table 3-1 RPM Files
File Name Path Descriptions
diagcored /opt/diagnostics/bin/
Diagnostics Core - Daemon
diagconfig.xml
diaguserconf.xml
/opt/diagnostics/etc/diag/
ViewCheck configuration file and user
configuration file.
diagcore /opt/diagnostics/etc/init.d/
Script to Start/Stop diagnostics core
