Functional Description
ARTM-9405 16x10GbE Installation and Use (6806800P45F) 46
4.3 PHY
The ARTM-9405 uses four NetLogic NLP10142 to provide 2x QSFP interfaces and 8x SFP+
interfaces on the face plate.
4.3.1 Management Interface
The Netlogic NLP10142 supports IEEE802.3 Clause 45 station management interface. The
MDC/MDIO signals are connected to Marvell switch device of the ATCA-9405 front board.
4.4 Private I2C Bus
Two private I2C bus on the ARTM-9405 16x10GbE are implemented as a bit banging interface
at the MMC.
Number of power draw
levels 1 The amount of possible power levels
Early Power Draw Levels,
Watt - Complete early power level including MMC
Steady state Power Draw
Levels, Watt ? Complete steady power consumption including IPMC
and RTM
Transition from early to
steady levels, sec 0s -
Table 4-8 Power Configuration (continued)
Item Value Description
Table 4-9 Private I2C Port
MMC Port Private I2C Signal
PG.4 RTM_PVT_I2C_0_SCL
PG.2 RTM_PVT_I2C_0_SDA
PA.7 RTM_PVT_I2C_1_SCL
PA.1 RTM_PVT_I2C_1_SDA
