6000xl, 6000xl: glass d oor r each-in r efr igerat or, Delfield

background image

Project __________________________________

Item ____________________________________

Quantity ________________________________

CSI Section 11400

Approved _______________________________

Date ____________________________________

980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858

Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619

www.delfield.com

Delfield

®

Exterior: Top and bottom are constructed of 24-gauge

galvanized steel. Exterior sides are 0.032 aluminum. Front

housing is 22-gauge stainless steel.

Doors: Unit is provided with hinged glass front door(s).

Doors are provided with magnetic gaskets, self-closing,

edgemount hinges; and quick grip long length door handle(s).

Doors are field reversible with no drilling required.

Interior: Liner is constructed of seamless, one piece ABS

material with 15 molded shelf supports spaced 3.00” (7.6cm)

apart. Three epoxy coated wire shelves, rated at 250 lb. load

capacity each, are provided per section. Shelf supports are

also capable of holding two 12” x 20” pans (by others) or one

18” x 26” pan (by others) per level. Liner comes with a limited

lifetime warranty.

Units are completely insulated with a minimum of 2.00”

(5.08cm) high density foamed in place polyurethane.

Interior is lit by one 15-watt fluorescent light on one door

models, one 40-watt fluorescent lights on two door models

and three 15-watt fluorescent lights on three door models.

Lights are located outside of the food zone. Fluorescent

lights are operated with a manual on/off switch.

Refrigeration system: All components are mounted to

the exterior cabinet ceiling, outside the food zone and are

assembled as one piece and can be removed as one piece.

Environmentally friendly R404A refrigerant is used. System

has the capability of maintaining between 27˚F and 40˚F in

heavy use food service operations. Refrigerant is metered

using a highly responsive thermostatic expansion valve.

System is controlled using Delfield’s ACT-Advanced Control

Technology electronic temperature control, which provides

improved pull down times, reducing compressor cycling and

longer compressor life with lower energy consumption.

Control system uses adaptive defrost to assure evaporator

coil is free of ice and operating at optimum efficiency.

Evaporator condensate is eliminated using an energy efficient

hot gas system.

Others: Unit is supplied standard with a 10’ cord and plug,

attached.

Units are standard with legs. Legs are constructed of painted

metal and are 6” high with 1” adjustability to compensate

for installation location factors. Shipped loose for field

installation.

Specifications

Standard Features

Options &
Accessories

Stainless steel front shroud

Aluminum sides

Seamless, Delrite® ABS interior liner

Top mounted refrigeration system

High performance Delflow refrigeration,
designed to maintain 27˚F to 40˚F

Easy to adjust epoxy shelves (three per
section)

Easy to read digital thermometer with
visual high/low temp alarms

10’ cord and plug attached

Edgemount door hinges

All doors are fully field rehingable

Environmentally friendly R404a refrigerant

One year parts and labor, 5 year compressor
warranty, limited lifetime liner warranty

Accepts 18” x 26” sheet pans

Standard glass door handles

6” adjustable legs (field installed)

Self closing doors with stay open feature at
120˚

Models

6000XL

Glass Door Reach-in Refrigerators

6000XL: Glass D

oor R

each-in R

efr

igerat

or

o

Extra shelves

o

Non standard hinging

6051XL-G

• 6025XL-G

Single section Full height doors

• 6051XL-G

Two section Full height doors

• 6076XL-G

Three section Full height doors

• 6025XL-GR

Remote Full height doors

• 6051XL-GR

Remote Full height doors

• 6076XL-GR

Remote Full height doors

• 6025XL-GH

Single section Half height door

• 6051XL-GH

Two section Half height door

• 6076XL-GH

Three section Half height door

• 6025XL-GHR

Remote Half height door

• 6051XL-GHR

Remote Half height door

• 6076XL-GHR

Remote Half height door
