Specifications are subject to change without notice.
PHYSICAL DATA FEATURES
TECHNICAL DATA
A compact, sub-bass loudspeaker designed to provide
high SPL extended bass to Adamson SpekTrix enclosures,
the SpekTrix Sub is equipped with two powerful AW18
18” Kevlar low frequency drivers in a tuned, vented
enclosure.
The cabinet is fully braced to minimize LF resonance and
maximize efficiency. Four sets of captured, precision-
machined aluminum rigging hardware are spring-loaded
and retract into the cabinet body when not in use; and
four NL8 connectors (two front, two back) enable easy
cable loop-thru regardless of the sub’s orientation.
- Dual AW18 18” Kevlar Bass drivers
- Frequency Response of 40 - 160 Hz
- Efficient Cabinet Design
- Durable, Waterborne Acrylic Finish
- Captured, Spring-Loaded Precision Rigging Hardware
- Easy Truck Pack with 2 cabinets per dolly paired with
optional waterproof softcovers for protection
technical specifications
Dimensions & Weight
Height (cm) 2” (58.5)
Width (cm) 28” (64)
Depth (cm) 2” (84)
Weight (Kg) 170lb (77)
Shape Rectangular
Box Finish
Hardware Finish Waterborne Acrylic
Back Bake Enamel
Flying Points
Captured spring-loaded
precision machined
aluminum
Protective grille 14 Gauge cold steel
Cabinet Construction
Rugged 15-ply Baltic
Birch, internally braced
Accessories Aluminum Dolly Board
Optional Accessories
Aluminum or Steel
Rigging Frame,
Waterproof Soft cover
Frequency Response
(+/-dB)
Full Range Preset 40Hz - 160Hz
Frequency Range
Xover Preset 5 Hz – 110 Hz
Maximum SPL
(Continuous)
12dB
Directivity Convertible to Cardioid
LF Section
Two Adamson AW18 18”
Kevlar Low Frequency
Drivers
Power Handling
(AES / Program / Peak) LF 600 / 1200 / 2400
Nominal Impedance
4 ohms
Sensitivity (2.8V @ 1m) 105.8dB
Connection
Neutrik Speakon™ NL8
(2 front, 2 rear)
