7” I

nt

eg

ra

te

d m

ul

ti f

orma

t HD Q

uad in

pu

t mo

ni

to

rs

07

LQM-071W

LQM-071W

LQM-071W

Name & Function of Each Part

FRONT

1. BUTTONS

- Press any button to bring up the OSD display as shown in the picture 2. Then selected item will display

in red. The OSD display disappears after 5 seconds, if no other control is made.

- Each button OSD indicates the feature, channel and value.

- For the button features with a channel selection, press the button repeatedly to change and select the

desired channel.

- For the button features with individual value selection, press the button repeatedly to increase the value

of the feature by 1.

- Rotate the FUNC ENC knob to change the value of selected item. The value will automatically store in the

memory once OSD disappears.

DISPLAY BRIGHT CHROMA MARKER SDI OUT FUNC1 MENU

MODE

CH SEL CONTRAST PEAKING VOLUME INTENSITY FUNC2 POWER

TALLY

LL

DISPLAY BRIGHT CHROMA MARKER SDI OUT FUNC1 MENU

DISPLAY BRIGHT CHROMA MARKER SDI OUT FUNC1 MENU

DISPLAY BRIGHT CHROMA MARKER SDI OUT FUNC1 MENU

DISPLAY BRIGHT CHROMA MARKER SDI OUT FUNC1 MENU

DISPLAY BRIGHT CHROMA MARKER SDI OUT FUNC1 MENU

DISPLAY BRIGHT CHROMA MARKER SDI OUT FUNC1 MENU

DP MODE

4P

CH SEL

CH1

BRIGHT

CH1

10

CONTRST

CH1

0

CHROMA

CH1

12

PEAKING

CH1

5
