LQM-071W
OSD Menu Contents
[4] REMOTE PART
Display Function
NONE No REMOTE function assigned.
R TLY C1 RED TALLY ON for CH1
R TLY C2 RED TALLY ON for CH2
R TLY C3 RED TALLY ON for CH3
R TLY C4 RED TALLY ON for CH4
G TLY C1 GREEN TALLY ON for CH1
G TLY C2 GREEN TALLY ON for CH2
G TLY C3 GREEN TALLY ON for CH3
G TLY C4 GREEN TALLY ON for CH4
MARK C1 MARKER DISPLAY ON for CH1
MARK C2 MARKER DISPLAY ON for CH2
MARK C 3 MARKER DISPLAY ON for CH3
MARK C4 MARKER DISPLAY ON for CH4
PWR STBY LCD Monitor Power ON
ACT SEL DISPLAY ACTIVE CH Select
1) PIN1
- Application : For all available inputs.
- Value Range : See Chart 1.
- Default Value : “R TLY C1”
- Function : Selects function for REMOTE PIN1.
2) PIN2
- Application : For all available inputs
- Value Range : See Chart 1.
- Default Value : “R TLY C2”
- Function : Selects function for REMOTE PIN2
3) PIN3
- Application : For all available inputs.
- Value Range : See Chart 1.
- Default Value : “R TLY C3”
- Function : Selects function for REMOTE PIN3.
