LQM-071W

7” I

nt

eg

ra

te

d m

ul

ti f

orma

t HD Q

uad in

pu

t mo

ni

to

rs

14

OSD Menu Contents

4) SAFETY AREA

- Application : For each input channel.

- Value Range : “OFF” , “80%” , “88%” , “90%” , “93%” , “98%” , “USER”

- Default Value : “OFF”

- Function : Selects the Safety Area Marker type for selected channel.

5) FIT MARKER

- Application : For each input channel.

- Value Range : “NO” , “YES”

- Default Value : “NO”

- Function : Activates the Fit Marker function. With Fit Marker On, the Safety Area is displayed relative to

the Marker in use.

6) MARKER COLOR

- Application : For each input channel.

- Value Range : “WHITE” , “GRAY” , “BLACK” , “RED” , “GREEN” , “BLUE”

- Default Range : “WHITE”

- Function : Controls the color of the Marker for selected channel.

7) USER MARKER H

- Application : For all available inputs.

- Value Range : 0 ~ 99

- Default Value : 99

- Function : Controls the position of user defined Horizontal Marker lines.

8) USER MARKER V

- Application : For all available inputs.

- Value Range : 0 ~ 99

- Default Value : 99

- Function : Controls the position of user defined Vertical Marker lines.

9) USER SAFETY AREA H

- Application : For all available inputs.

- Value Range : 0 ~ 99

- Default Value : 99

- Function : Controls the horizontal position of user defined Safety Area.

10) USER SAFETY AREA V

- Application : For all available inputs.

- Value Range : 0 ~ 99

- Default Value : 99

- Function : Controls the vertical position of user defined Safety Area.
