LQM-071W
OSD Menu Contents
1) DISP MODE
- Application : For all available inputs.
- Value Range : “4P” , “4P1W1V” , “4P3W” , “3P1W” , “3P1V” , “2P1W1V” , “2P2W” , “2P2V” , “1P” , “1P1W” ,
“1P1W1V” , “1P3W”
- Default Value : “4P”
- Function : Selects the image Display Mode. See Chart 2.
Value “P” stands for Input Picture, “W” stands for Waveform and “V” stands for Vectorscope.
2) ACT CH SEL
- Application : For all available inputs.
- Value Range : “CH1” , “CH2” , “CH3” , “CH4”
- Default Value : “CH1”
- Function : Selects Active Input Channel.
In Quad Display mode, active input channel always displays on the top left position and
Waveform/Vectorscope is displayed for this channel.
3) LVM DISPLAY
- Application : For each input channel.
- Value Range : “OFF” , “H40” , “H22” , “V40” , “V22”
- Default Value : “H40”
- Function : Selects the display mode of Embedded Audio Level Meter for each selected channel.
Only a group of Audio Level Meter for each selected channel is available. If the embedded audio
does not exist for selected input channel, the outside of LVM will be displayed in red.
4) SRC ID
- Application : For each input channel.
- Value Range : “OFF” , “MANUAL” , “ANC” , “AUTO”
- Default Value : “OFF”
- Function : Activates the ID display for selected display.
By selecting “MANUAL” option, user can display the edited SRC ID.
By selecting “ANC” option, monitor extracts the embedded ID string packet from selected SDI input.
By selecting “AUTO” option, “ANC” displays if available. If not, Manual SRC ID is displayed.
5) SRC STRING
- Application : For each input channel.
- Value Range : Up to 8 digits of ASCII String
- Default Value : N/A (Factory Value: CHANNEL1~4)
- Function : Edits SRC ID of selected input display.
Select the desired character by turning the MENU ENC knob, then press the MENU ENC SW to select
the next character. See Chart 3 for all available characters.
