LQM-071W

Product Specification

7” I

nt

eg

ra

te

d m

ul

ti f

orma

t HD Q

uad in

pu

t mo

ni

to

rs

23

* Above specifications may be changed without notice
** SMPTE-372M mode is an optoin

4 x BNC


1 x BNC

Analog
HD-SDI
SD-SDI
Composite
SMPTE-274M

SMPTE-296M
SMPTE-260M
SMPTE-125M
ITU-R BT.656

Input

Output

Input Signal

Analog Input Spec
SDI Input Signal
Formats

Audio IN

Audio OUT
Power Consumption
Power Input
Operating Temperature
Storage Temperature
Main Body Dimensions (mm/inch)
Main Body Dimensions (with stand)
Weight
Accessory
Option

SDI A/B/C/D Channel Input
Analog Composite A/B/C/D Channel Input
(Share BNC with SDI Input)
SDI A/B/C/D Channel Selected Output
Analog Composite AD Converted Output
Composite
1.458Gbps
270Mbps
1.0Vpp (With Sync)
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
720p (60/59.94/50)
1035i (60/59.94)
480i (59.94)
576i (50)
Embedded Audio
Analog Stereo (Phone Jack)
Analog Stereo (Phone Jack)
18W
12V DC
-20° to 40° (-4° to 104°)
-30° to 50° (-22° to 122°)
203 x 131 x 60 (8.39 x 5.16 x 2.36)
217 x 143 x 69 (8.54 x 5.63 x 2.72)
1Kg/2.2lb
DC Power Adapter, Camera Mount
19” Rack Mountable Kit (3U, Dual Monitor)
