OSD MENU Organization

[1] PICTURE PART

1. MENU CONTROL

2. MENU STRUCTURE


COLOR

MARKER
REMOTE

DISPLAY

SYSTEM

BRIGHT

CH1

0

CONTRAST

CH1

0

CHROMA

CH1

0

PEAKING

CH1

0

ASPECT RATIO

CH1

4:3

INT PATTERN OFF

CH1

0

CH2

0

CH3

0

CH4

0

- User can control the features of the monitor using the Menu.

- To control the Menu, use MENU button, MENU ENCODER and MENU ENC SW.

* MENU Button : ROOT Menu POP-UP, Return to previous Menu,

Cancel value change (Undo).

* MENU ENCODER : Navigate the Menu, Change the value.

* MENU ENC SW : Select the Menu.

- Press and hold for 1 second to activate Menu.

- To confirm and activate the change made in the Menu, press the MENU ENC SW. If Menu button is

pressed after any change was made in the Menu, the change will not be stored and will return to the

previous value.

1) BRIGHT

- Application : For each input channel.

- Value Range : -50 ~ 49

- Default Value : 0

- Function v: Controls the brightness of the selected input display.

2) CONTRAST

- Application : For each input channel.

- Value Range : -50 ~ 49

- Default Value : 0

- Function : Controls the contrast of the selected input display.
