LQM-071W

7” I

nt

eg

ra

te

d m

ul

ti f

orma

t HD Q

uad in

pu

t mo

ni

to

rs

20

OSD Menu Contents

6) TIMECODE DISPLAY

- Application : For each input channel.

- Value Range : “OFF” , “ATC” , “VITC” , “AUTO”

- Default Value : “OFF”

- Function : Selects the Timecode display for selected display.

“ATC” displays for SDI input with embedded timecode.

“VITC” displays for VITC timecode included in SD-SDI VBI section.

“AUTO” displays “ATC” if available, but if not, VITC is displayed

If Timecode is not available, “--:--:--:--” is displayed

7) WAVE INTENSITY

- Application : For all available inputs.

- Value Range : 0 ~ 31

- Default Value : 3

- Function : Controls the intensity of Waveform/Vectorscope. If the input display is too dark or bright,

use this function to change the intensity of the Waveform/Vectorscope for better view.

1) SET DEFAULT

- Application : For all available inputs.

- Value Range : “NO” , “YES”

- Default Value : “NO”

- Function : Initializes all fixed values back to default setting.

* Exception : Custom 1~3 in Color menu.

Fixed SRC ID String

2) BACK LIGHT

- Application : For all available inputs.

- Value Range : 0 ~ 63

- Default Value : Color calibration value

- Function : Controls the Backlight value of the LCD panel.

3) AUDIO VOLUME

- Application : For all available inputs.

- Value Range : 0 ~ 49

- Default Value : 30

- Function : Controls the volume of the built-in speaker.

“SPACE” ! " # $ % & ' ( ) * + , - . /

0 1 2 3 4 5 6 7 8 9 : ; < = > ? @

A B C D E F G H I J K L M N O P Q R S T U V W X Y Z[ \ ] ^ _ `

a b c d e f g h I j k l m n o p q r s t u v w x y z { | } ~

[6] SYSTEM PART
