3) CHROMA

- Application : For each input channel.

- Value Range : -50 ~ 49

- Default Value : 0

- Function : Controls the saturation of the selected input display.

4) PEAKING

- Application : For each input channel.

- Value Range : 0 ~ 19

- Default Value : 0

- Function : Controls the sharpness of the selected input display.

5) ASPECT RATIO

- Application : For each input channel.

- Value Range : “4:3” , “16:9”

- Default Value : “4:3”

- Function : If selected input is in SD, input diplays in 4:3 or 16:9 aspect ratio.

6) INT PATTERN

- Application : For all available inputs.

- Value Range : “OFF” , “WHT100%” , “WHT85%” , “WHT50%” , “WHT25%” , “GRN100%” , “GRN85%” ,

“GRN50%” , “GRN25%” , “BLU100%” , “BLU85%” , “BLU50%” , “BLU25%” , “RED100%” , “RED85%” ,

“RED50%” , “RED25%”

- Default Value : “OFF”

- Function : Displays flat image pattern used for such as color calibration.

1) COLOR TEMP

- Application : For all available inputs.

- Value Range : “3200K” , “5000K” , “5600K” , “6500K” , “9300K” , “CUSTOM1” , “CUSTOM2” , “CUSTOM3”

- Default Value : “6500K”

- Function : Controls Color Temperature of display.

2) GAIN RED

- Application : For all available inputs.

- Value Range : -50 ~ 49

- Default Value : Color calibration Value (No default value for custom1/2/3)

- Function : Controls gain value of Red.

3) GAIN GREEN

- Application : For all available inputs.

- Value Range : -50 ~ 49

- Default Value : Color calibration Value (No default value for custom1/2/3)

- Function : Controls gain value of Green.

LQM-071W

7” I

nt

eg

ra

te

d m

ul

ti f

orma

t HD Q

uad in

pu

t mo

ni

to

rs

12

OSD MENU Organization

[2] COLOR PART
