Top Global USA. ----MB9000 User Guide
2.2
Write Down the Product’s Identification
Before MB9000 installation, please write down following information on the MB9000 label:
z
Serial
Number
z
MAC
address
2.3
Power up the MB9000
Connect the MB9000 power supply (refer to Figure 2-2).
Figure2-2 Ports description
1. Power Jack
2. WLAN Antenna
3. PC Card Slot B
4. PC Card Slot A
5. Console Port (RS232)
6. Ethernet WAN Interface (RJ45)
Figure 2-1 Top View
The MB9000 power supply accepts any input AC voltage in the range of 100-240 VAC.
- 7 -
