Thor 1-4 HDMI to ATSC Modulators 8VSB - Manual (Page 6)

H-4HDMI-ATSC-IP
1.3 Specifications
Encoding Section
Video
Encoding MPEG2 HD/MPEG4 HD
Input HDMI*4
Resolution
1920*1080_60P, 1920*1080_50P, (-for MPEG4/H.264)
1920*1080_60i, 1920*1080_50i,
1280*720_60p, 1280*720_50P
720*480_60i, 720*576_50i
Audio
encoding MPEG1 Layer II, (MPEG2-AAC, MPEG4-AAC available )
Sample rate 48KHz
Bit rate 64kbps, 96kbps,128kbps, 192kbps, 256kbps, 320kbps
ATSC Modulator Section
Standard ATSC A/53
Constellation 8 VSB
RF Output Level 26~-10dbm (81~97dbµV), 0.1db step
MER ≥42dB
RF frequency 30~960MHz, 1KHz step
System
Local interface LCD + control buttons
Remote management Web NMS
output 2 ASI out (BNC type);
1 IP out (RJ45, 100M)
NMS interface RJ45, 100M
Language English
General
Power supply AC 100V~240V
Dimensions 482*400*44mm
Weight 5 kgs
Operation temperature 0~45℃
