Thor 1-4 HDMI to ATSC Modulators 8VSB - Manual (Page 14)

H-4HDMI-ATSC-IP
 A: the symbol of different carrier output. “A”, “B”, “C”, and “D” alternate
constantly with the following output frequency.
 XXX.XX MHz indicates the current output frequency (range: 30~960MHz) of its
corresponding carrier output.
 P1: Program 1; P2: Program 2; P3: Program 3; P4: Program 4
 X.XX Mbps: indicates the encoding bit rate of each channel respectively.
3.3 General Settings for Main Menu
By pressing “Lock” key on the front panel, enter the main menu. The LCD will display the
following pages:
1) Press UP/DOWN buttons to specify menu items, and then press ENTER to enter the
submenus as below:
2) Alarm Status
The alarm indicator will turn on if there is no A/V signals inputting or outputting bit
rate overflows. User then can enter this menu to check the error type.
3) Encode Setting
Under this submenu, the LCD will show “2.1 Input 1”, “2.2 Input 2” and “2.3 ASI”.
Under submenus 2.1 or 2.2, user could set the video encoding format and bit rate, and
set audio encoding bit rate and also read the audio encoding format of the program from
the HDMI input.
1 Alarm Status
2 Encode Setting 3 Modulate Setting
4 IP Output Setting
5 Network Setting
6 Saving Config 7 Loading Config
8 Version
2.1 Input 1
2.2 Input 2 2.3 ASI
