H-4HDMI-ATSC-IP
Chapter 4 WEB NMS Operation
For setting configurations you can use the front panel; also you are able to control and set
the configurations on any computer by connecting the device to the web NMS Port. You
should ensure that the computer’s IP address is different from the THOR 4-ADHD’s IP
address; otherwise, it would cause IP conflict.
4.1 login
The default IP of this device is 192.168.0.136. We can modify the IP through the front
panel.
Connect the pc and the device with net cable, and use ping command to confirm they are
on the same network segment.
E.G. the PC IP address is 192.168.99.252, we then change the device IP to 192.168.99.xxx
(xxx can be 0 to 255 except 252 to avoid IP conflict).
Use any web browser to connect the device with the PC by inputting the Encoder &
Modulator’s IP address in the browser’s address bar and press Enter.
It will display the Login interface as Figure-1. Input the Username and Password (Both
the default Username and Password are “admin”.) and then click “LOGIN” to start the
device setting.
Figure-1
