G. Use a 7mm socket to remove the four coil

pack bolts and move the coil pack toward the
passenger’s side and out of your way.

H. Remove the 13mm bolt, nut and stud bolt

securing the coil bracket to the cylinder head.
(See Fig. 1.1-f.)

Fig. 1.1-f

REMOVE THREE

RETAINING NUTS

Fig. 1.2-a

1.2

COOLANT RESERVOIR REMOVAL

A. Drain approximately one gallon of coolant

from the radiator into an appropriate container.

B. Remove the large hose from the coolant reser-

voir and drain the contents of the reservoir
into a container.

C. The coolant reservoir is secured by three nuts.

(See Fig. 1.2-a.) Use a 10mm socket, remove
the reservoir by removing these nuts and place
the reservoir aside.

D. Remove the upper radiator hose and set aside

to be modified in a later step.
