Appendix B: Vehicle Power Management Setup
Vehicle Power Management Setup
Startup and Shutdown Voltage Setting
1.
If the input voltage setting is 12V :
set the startup voltage to 11.5V and the shutdown voltage to 10.5V.
If the input voltage setting is 12V :
set the startup voltage to 12V and the shutdown voltage to 11V.
If the input voltage setting is 12V :
set the startup voltage to 12.5V and the shutdown voltage to 11.5V.
If the input voltage setting is 12V :
set the startup voltage to 12.5V and the shutdown voltage to 11V.
Advanced
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Startup,Shutdown Setting Power Management Configuration
** External +5V & +12V Power Setting **
External Power
** Startup & Shutdown Voltage Setting **
Input Voltage
Startup,Shutdown
**Delay Time Setting**
Power On Delay
Power Off Delay
[Turn Off Both]
12 V
[(11.5,10.5)/(23,21)]
Startup,Shutdown
(11.5,10.5)/(23,21)
(12.0,11.0)/(24,22)
(12.5,11.0)/(25,22)
(12.5,11.5)/(25,23)
