NDiS OPS-M50 User Manual
Chapter 3: System Setup
5. Insert the wireless LAN module into the Mini PCI Express slot at a 45
degrees angle until the gold-plated connector on the edge of the
module completely disappears inside the slot.
6. Push the module down then secure it with mounting screws and attach
one end of the RF cable onto the WiFi module.
Mounting
Screw
Attached RF Cable to
the Module
