APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
Chapter 3: System Setup
Installing a CFast Card
1. The CFast card socket is located on the rear top side of the chassis.
CFast card socket
Mounting
screw
2. Remove the mounting screws of the CFast socket’s cover.
