Chapter 2: Jumpers and Connectors
NISE 101 User Manual
SATA Power Connectors
Connector size: 1x4 4-pin wafer, 2.0mm pitch
Connector location: PWR1 and PWR2
1 4
Pin Definition
1 +12V
2 GND
3 GND
4 5V
CPU Fan Connector
Connector size: 1x3 3-pin wafer, 2.54mm pitch
Connector location: CPU_FAN
Pin Definition
1 GND
2 +5V
3 FAN_TAC1
3 1
