Dugan Model E User Guide
47
Chapter 9: Connector Pinouts
Table 9-1 Analog I/O jacks
Table 9-2 10 BASE T (Ethernet, TCP/IP)
Signal
Tip Input
Ring Output
Sleeve Ground
Pin Signal
1 T2
2 T1
3 R2
4 n/c
5 n/c
6 R1
7 n/c
8 n/c
