Forensic ComboDock v5 User Manual A9-000-0041 REV 1.0 - 3 -
1. Pre-Setup
1.1 Check the accessories packaged with your Forensic ComboDock
Forensic ComboDock v5 ships with everything you need to get started. Please contact CRU if any items
are missing or damaged. The box should contain:
1.2 Take a moment to familiarize yourself with the parts of your new Forensic
ComboDock. This will aid you in the remaining steps.
Contains Number
Forensic ComboDock unit 1
AC adapter & power cord 1
USB 3.0 cable 1
FireWire 800 cable 1
FireWire 400 cable 1
eSATA cable 1
SATA drive attachment cable 1
IDE cable 1
Molex mini-fit to legacy power cable 1
Metal drive plate 1
Packet of screws and bumpers 1
Quick Start Guide and Warranty Info 1
A eSATA connector for connecting SATA drives
B 4-pin square connector for power cable to the drive
C 40-pin IDE header for external IDE cable attachment
D FireWire 400 connector
E dual FireWire 800 connectors
F USB 3.0 connector
G eSATA connector
H Power input from AC adapter
I SATA power input
J USB mode switch (see section 4)
