⇒ Buttons:
Once in Test mode the functions of the buttons will be:
- RESET button: Pressed when this mode is finished and prepares the CBS
for normal working.
- MODE button: Allows the selection of the channel to be tested.
- SELECT button: Starts the testing of the selected channel.
⇒ LEDs
The CBS-8 also checks the working of the LEDs. This test consists of all LEDs
being on for all the time it is in Test mode.
Ed
Rd
