CIRCUTOR CBS8 (Available until stocks) User Manual
Page 13
----- Relay Station CBS-8 -------- --- Page No. 12
4.1.- Normal mode
The equipment has a 2 line LCD display:
Ed
Rd
When the CBS-8 is switched on the following information appears on the
display for a few moments:
CBS 8
xxxx
(
Software version
After a few seconds the equipment is ready to be used and displays one of the
possible screens according to the set up.
NB: If the word “max” appears on the screen during normal operation, it
means that the detected current is higher than the preset range. In the event of this
happening the measurement will not be accurate.
