----- Relay Station CBS-8 -------- --- Page No. 14
- SELECT button: According to the preset display mode, the function of this
button will be:
- UIS.2 or UIS.3 mode: Changes the channel displayed
- UIS.4 mode: Advances within history log.
- MODE and SELECT button: Enters set up mode. Depending on the switch
situation “PROG” will perform the following operations:
- Down: Enters set up allowing all configuration parameters to be
changed.
- Up (Blockable position): Enters set up mode, only allowing the
equipment’s configuration to be checked. It does not allow the
configuration of the equipment to be changed.
- RESET and SELECT button: Allows the station to be up dated.
⇒ LEDs
The 5 LEDs on the CBS-8 display the following parameters:
- CPU LED: Always flashes when the equipment is working.
- COMM LED: Flashes when communication via the RS485 series channel is
established.
- Rd LED: Is lit when automatic reclosures are permitted.
- LED: Is lit when any channel has tripped. It will always flash when any
channel is in pre-alarm and there are no tripped channels.
- Ed LED: Is lit when any channel is blocked.
