Dimension One Spas 01510-1030 User Manual
Page 34
Sonic Immersion System Dealer Installation Guide
3. Now place the green ground wire that you just inserted into
the lower control box over the screw, replace 5/16” nut, and
secure with 5/16” nut driver or wrench.
4. Connect the white and black wires to the pins as outlined in
the following table.
Table 5 Pin Connectors
Board Description
Pin Connections
MSPA-MP for U.S.
and Canada
Green – ground
White – P-40
Black - -P-55
30
