Mechanical Data
MODEL NUMBER VOLTAGE AMPS
STORAGE
CU.FT.
SHELVES SQ.FT.
NO. OF
SHELVES
UNIT H.P.
BTU/HR
SYSTEM CAP
SHIP
WEIGHT
NEMA
PLUG
ENERGY
(KWH)
SSRRI1-G, SARRI1-G, SMRRI1-G 115 7.8 36.15 N/A N/A 1/3 2488
476lbs
(216kg)
5-15P 5.46
SSRRI2-G, SARRI2-G, SMRRI2-G 115 16.0 74.72 N/A N/A 1/2 5465
768lbs
(348kg)
5-20P 9.28
SSRRI3-G, SARRI3-G, SMRRI3-G 115/208-230 10.0 113.28 N/A N/A 3/4 6920
1044lbs
(474kg)
N/A 17.12
ELEVATION VIEW
SSRRI1-G, SARRI1-G,
SMRRI1-G
ELEVATION VIEW
SSRRI2-G, SARRI2-G,
SMRRI2-G
PLAN VIEW
SSRRI1-G, SARRI1-G,
SMRRI1-G
PLAN VIEW
SSRRI2-G, SARRI2-G, SMRRI2-G
PLAN VIEW
SSRRI3-G, SARRI3-G, SMRRI3-G
ELEVATION VIEW
SSRRI3-G, SARRI3-G,
SMRRI3-G
END VIEW
ALL MODELS
