C a b l e s a n d A c c e s s o r i e s
Cables and Accessories
In addition to your TV and the equipment that shipped with your DIRECTV HD DVR (shown below), you’ll need a satellite dish
antenna, an off-air antenna—both of which should be properly mounted before you connect the HD DVR—and a standard phone line
(see page 3 for details) for full functionality.
Composite A/V Cable
(red, white, yellow)
25' Phone Cord
Power Cord
Component Video Cable
(red, blue, green)
1.
These are the basics:
2.
The carton contains one of each of the following:
HD DVR
DIRECTV Access Card
Remote Control
and 2 AA
Batteries
Phone Line Splitter
1
0
2
3
7
9
8
4
6
5
Record
Mute
Info
Exit
Page
Vol
Chan
S l o w
Select
TV
SAT
Clear
TV
Power
TV
Input
En
ter/Last
( )
-
D I R E C T V
P la y
G uid e
L is t
D I R E C T V
Liv
e TV
Ratio
S-Video Cable
Optical Digital Audio Cable
3.
You may need to purchase additional cables for some setups:
Extra Composite A/V Cable
(Adding a VCR or DVD recorder
on page 18.)
