OPGP-34-A4B3RA
DELTA ELECTRONICS, INC.
2 Revision: S2
12/26/2006
www.deltaww.com
1. Absolute Maximum Ratings
Parameter Symbol Min. Typ. Max. Unit Note
Storage Temperature Ts -40 85 ºC
Storage Ambient Humidity H A 5 95 %
Power Supply Voltage V CC 0 5 V
Signal Input Voltage -0.3 Vcc+0.3 V
Optical Input Power (Peak) 7 dBm
Lead Soldering Temperature T
SOLD
260 ºC
Lead Soldering Time t
SOLD
10 sec
2. Recommended Operating Conditions
Parameter Symbol Min. Typ. Max. Unit Note
Operating Ambient Temperature T A -5 70 ºC
Ambient Humidity H A 5 90 % Non-condensing
Power Supply Voltage V CC 3.13 3.3 3.47 V
Power Supply Current I CC 350 mA
Power Supply Noise Rejection 100 mVp-p 100Hz to 1MHz
Data Rate of Transmitter 1244.16 Mbps
Data Rate of Receiver 2488.32 Mbps
Line Code Scrambled NRZ
Transmission Distance 20 km
3. Specification of Transmitter
Parameter Symbol Min. Typ. Max. Unit Note
+1 +5 dBm B.O.L -Note (1)
Average Launched Power P
O +0.5 +5 dBm E.O.L -Note (1)
Optical Extinction Ratio ER 10 dB
Center Wavelength λ
C
1260 1310 1360 nm DFB Laser
-20dB Spectrum Width (RMS) σ 0.3 1 nm
Side Mode Suppression Ratio SMSR 30 dB
Transmitter OFF Output Power P
Off
-45 dBm
Optical Rise/Fall Time t
r
/t
f
200 ps Note (2)
Tx Enable Ton 16 bits 12.8ns
Tx Disable Toff 16 bits 12.8ns
Transmitter Reflectance -6 dB
Tolerance to the Transmitter’s
incident Light Power
-15 dB
Jitter Generation 0.33 UIp-p 4KHz~10MHz
Output Eye Mask Compliant with ITU-T G.984.2 Note (3)
ORL of ODN at Oru and Ord 32 dB
Note (1). Launched power (avg.) is power coupled into a single mode fiber.
B.O.L = Begin of Life, E.O.L = End of Life
Note (2). These are unfiltered 20-80% values.
