Maintenance
51
pack the calibrator securely, using the original shipping
container if it is available. Send the equipment postage
paid and insured, to the nearest Service Center. Fluke
assumes no responsibility for damage in transit.
The Fluke 725 calibrator covered by the warranty will be
promptly repaired or replaced (at Fluke’s option) and
returned to you at no charge. See the back of the title
page for warranty terms. If the warranty period has
expired, the calibrator will be repaired and returned for a
fixed fee. If the calibrator or pressure module is not
covered under the warranty terms, contact an authorized
service center for a price quote for repair.
To locate an authorized service center, refer to
“Contacting Fluke” at the beginning of the manual.
Replacement Parts
Table 9 lists the part number of each replaceable part.
Refer to Figure 24.
Table 9. Replacement Parts
Item
Description
PN
Qty.
1
Case top
664232
1
2
LCD mask
664273
1
3
Elastomeric strips
802063
2
4
Input/output bracket
691391
1
5
LCD bracket
667287
1
6
Mounting screws
494641
11
7
Backlight
690336
1
8
LCD
690963
1
9
Keypad
690955
1
10
Case bottom
664235
1
11
AA alkaline batteries
376756
4
12
Case screws
832246
4
13
Battery door
664250
1
14
Accessory mount
658424
1
15
Tilt stand
659026
1
16
Battery door 1/4-turn
fasteners
948609
2
17
TL75 series test leads
855742
1
18
Test lead, red
Test lead, black
688051
688066
1
1
19
725 Product Overview
Manual
1549644
1
20
AC72 alligator clip, red
AC72 alligator clip, black
1670641
1670652
1
1
21
CD ROM, contains User
Manual
1549615
1
22
Input Decal
690948
1
23
Fuse 0.05A/250V
2002234
2
