Woodhaven 8610-8611: Cup Marking Jig User Manual
Please read carefully, Parts list
Parts List:
You will receive only ONE of the Bases listed below:
Part Description
Quantity
8610B
35mm Cup Marking Plate . . . . . . . . . . 1
8611B
26mm Cup Marking Plate . . . . . . . . . . 1
8610A
1/2" Cap . . . . . . . . . . . . . . . . . . . . . . . . . . 1
8610C
1/4" Cap . . . . . . . . . . . . . . . . . . . . . . . . . . 1
8610D Indexing
Plate
. . . . . . . . . . . . . . . . . . . . . 1
8610E
Indexing Plate Riser . . . . . . . . . . . . . . . 1
4208
7-7/8" One Track . . . . . . . . . . . . . . . . . . 1
8610 or 8611 Adj.
Cup Marking Jig
Please Read Carefully!
Part# Description Qty.
5771B 3/4"
Screw 2
Part# Description Qty.
HB030 1"
Bolt
1
Part# Description Qty.
5765B Offset
Oval
Nut
2
Part# Description Qty.
WB002 Washer
1
Part# Description Qty.
BUSH050 3/8" Spacer
5
1
Part# Description Qty.
BUSH001 1/8"
Spacer
3
Part# Description Qty.
MF035 1/2"
Screw 2
Part# Description Qty.
5521 Thumb
Nut 1
Part# Description Qty.
5860 Ratchet
Handle
1
Part# Description Qty.
BUSH5050 1/2" Spacer
1
Part# Description Qty.
MP200 2"
Screw
1
Part# Description Qty.
BUSH004 5/8" Spacer
2
Part# Description Qty.
HB050 1-1/2"
Bolt
1
Part# Description Qty.
MP150 1-1/2"
Screw 2
Part# Description
Qty.
5863 Ratchet Hand. w/stud 1
