27AUG2010 GT500 OEM POWER PACK
2
1. OEM SUPERCHARGER PULLEY REMOVAL, CONT’D
D. Using a 3/8” drive breaker bar on the tensioner,
remove the serpentine belt from the supercharger
pulley. (See Figure 1-c & 1-d)
E. The center plug on the supercharger will need to
be removed so as not to damage it when remov-
ing or installing the pulley. Using a flat screw driver
or upholstery tool, pry the plug off the supercharg-
er snout. (See Figure 1-e)
Fig. 1-c
Fig. 1-d
Fig. 1-e
