1986-1993 High-Output Mustang
Part No. 4FA218-040L/048L
PARTS LIST
PART NUMBER DESCRIPTION QUANTITY
2F328-010 V3-SI SUPERCHARGER ASSEMBLY 1
2E038-333 8-GR 3.33" SUPERCHARGER DRIVE PULLEY 1
8R101-002 8 & 10-RIB PULLEY RETAINER ASSEMBLY 1
4FA111-021 MOUNTING BRACKET ASSEMBLY 1
4FA011-021
MOUNTING BRACKET
1
4FA010-034
MOUNTING PLATE
1
4FA015-015
ALTERNATOR STAY
1
4FA017-021
SMOG PUMP SPACER
1
7A375-625
3/8-16 x 6-1/4" BOLTS
2
7A375-700
3/8-16 x 7" BOLT
1
7A437-175
7/16-14 x 1-3/4" BOLT
1
7A375-175
3/8-16 x 1-3/4" BOLT
1
7A375-650
3/8-16 x 6-1/2" BOLT
1
7A375-200
3/8-16 x 2" BOLT
1
7A375-075
3/8-16 x 3/4" BOLT
1
7F375-016
3/8-16 NUTS
2
7A375-100
3/8-16 x 1" BOLTS
7
7K375-040
3/8"AN960 FLAT WASHERS
5
7J375-044
3/8"SAE WASHERS
10
7J012-092
12mm FLAT WASHER
1
4FA110-011
SPRING TENSIONER
1
MOUNTING ASSEMBLY
4FA010-011 TENSIONER MOUNTING BRACKET
1
7A375-100
3/8-16 x 1" BOLTS
2
7J375-044
3/8"SAE WASHERS
2
7F375-016
3/8-16 NUT
1
7A500-350
1/2-13 x 3-1/2" CARRIAGE BOLT
1
7F500-013
1/2-13 HEX NUT
1
7J012-092
12mm FLAT WASHER
1
4FA111-042
SUPERCHARGER
1
BELT TENSIONER ASSEMBLY
7J012-092
12mm FLAT WASHERS
3
4FA011-032
BELT TENSIONER PLATE
1
7C012-020
12mm x 1.75" x 20mm BOLTS
3
7G010-175
12mm x 1.75" NUT
1
4FA016-170
WIDE IDLER PULLEY
1
2A017-011
8-RIB IDLER SPACER
1
7C012-065
12mm x 1.75" x 65mm BOLT
1
4FA116-041
CRANK PULLEY ASSEMBLY
1
4FA018-021
8-GR 6.0/6.87 CRANK PULLEY
1
7A375-178
3/8-16 x 1-3/4" BOLTS
4
7J375-044
3/8"SAE WASHERS
4
7L375-075
3/8" LOCK WASHERS
4
2A048-545
BELT
1
4FA238-068
FMU (WITH LINES)
1
6Z110-111 12:1 BLACK FUEL MANAGEMENT UNIT 1
4FA145-010
MALE FUEL ASSEMBLY
1
4FA145-020
FEMALE FUEL LINE ASSEMBLY
1
7U030-046
5/32" x 54" VACUUM LINE
1
7E010-046
#8 x 3/4" SHEET METAL SCREWS
2
7U100-055
6" NYLON TIE-WRAPS
2
PART NUMBER DESCRIPTION QUANTITY
4FA139-096
PCV BYPASS KIT
1
8H040-020
3/8" INLINE FILTER
1
7U375-052
3/8" VACUUM CAP
1
7U030-056
3/8" x 22" FUEL HOSE
1
4FA114-023 RADIATOR HOSE ASSEMBLY
1
4FA014-011
RADIATOR PIPE
1
7R002-024
#24 HOSE CLAMPS
2
5A101-001
STAND ALONE ASSEMBLY
1
7P156-082
5/32" TEE
1
5A002-002
FORD EFI WIRING HARNESS
1
5A001-001
STAND ALONE IGNITION RETARD
1
7U030-046
5/32" x 24" VACUUM LINE
1
4FA112-030
DISCHARGE ASSEMBLY
1
4FA012-030
ALUMINUM DISCHARGE TUBE
1
7S275-200
2-3/4" x 2" SLEEVE
1
7S300-200
3" x 2" SLEEVE
1
7R002-044
#44 HOSE CLAMPS
2
7R002-048
#48 HOSE CLAMPS
2
8D001-001
BYPASS VALVE
1
7P750-100 3/4"NPT x 1” STRAIGHT HOSE FITTING 1
7U134-145
1" x 4-1/2" HEATER HOSE
1
7U134-130
1" x 3" HEATER HOSE
1
7R002-016
#16 HOSE CLAMPS
4
7P156-082
5/32" TEE
1
7U030-046
5/32" x 24" VACUUM LINE
1
4FA112-015
AIR INTAKE ASSEMBLY
1
7S350-200
3-1/2" x 2" SLEEVE
1
4FA012-013
90° INTAKE ELBOW
1
4FA013-010
AIR CLEANER COVER
1
8H040-040
AIR FILTER
1
7J006-093
6mm WASHERS
2
7P375-097
3/8"NPT x 3/8" BARB
1
7S300-100
3" x 1" SLEEVE
1
7E010-046
#8 x 3/4" SHEET METAL SCREWS
2
7R002-056
#56 HOSE CLAMPS
2
7U035-000
3-1/2" x 12" FLEX HOSE
1
7R002-052
#52 HOSE CLAMPS
2
7P750-102
3/4"NPT x 1" 90° HOSE FITTING
1
8F201-265
T-REX
®
PUMP ASSEMBLY
1
7F008-032
8-32 HEX LOCK NUTS
8
7J008-001
#8 FLAT WASHERS
8
7P312-003 5/16" FEMALE FUEL CONNECTORS
2
7P312-001
FORD FUEL FITTING ADAPTER
1
7R004-002
17.0 STEPLESS CLAMPS
2
7R004-001
15.7 STEPLESS CLAMPS
3
7R001-004
#4 HOSE CLAMPS
2
7U314-001
#8 LORD MOUNTS
4
5W001-001
WIRE TAP
1
7U032-016
3/8" x 6" FUEL HOSE
1
7E010-050
#12 x 1/2" SHEET METAL SCREW
1
7U375-135
ADHESIVE MOUNTING PADS
4
7U100-055
6" NYLON TIE-WRAPS
6
4FA020-030
T-REX PUMP TEMPLATE
1
8F101-200
T-REX WIRING ASSEMBLY
1
7U031-018
5/16" x 24" HP FUEL HOSE
1
8F002-265
90° T-REX INLINE FUEL PUMP
1
5W001-010
16-14GA FEMALE SLIDE
1
5W001-002
FUSE TAP
1
5W001-011
16-14GA EYELETS
2
7U100-044
4" NYLON TIE-WRAPS
4
7U031-018
5/16" " 30" MPI HOSE
1
009035
LUBE ASSY
1
IMPORTANT: Before beginning installation, verify that all parts are included in the
