Vortech 1986-1993 Ford 5.0 Mustang User Manual
Page 3
P/N: 4FA020-010
© 2009 Vortech Engineering, Inc.
All Rights Reserved, Intl. Copr. Secured
16APR09 v4.1(86-93 5.0 Mus (4FA v4.1))
iii
TABLE OF CONTENTS
FOREWORD .....................................................................................................................................ii
TABLE OF CONTENTS ....................................................................................................................iii
IMPORTANT NOTICE .......................................................................................................................iv
TOOL & SUPPLY REQUIREMENT...................................................................................................v
PARTS LIST - 1986-1993 MUSTANG (Internally Lubricated) ...........................................................vi
PARTS LIST - 1986-1993 HIGH-OUTPUT MUSTANG .....................................................................vii
PARTS LIST - 1986-1993 HIGH-OUTPUT MUSTANG (Internally Lubricated) .................................viii
PARTS LIST - 1986-1993 RENEGADE MUSTANG..........................................................................ix
PARTS LIST - 1986-1993 SUPER HIGH-OUTPUT MUSTANG .......................................................x
MSD IGNITION SYSTEM ..................................................................................................................xii
1.
PREPARATION/REMOVAL ..................................................................................................1
2.
CRANKSHAFT PULLEY .......................................................................................................1
3.
OIL DRAIN ............................................................................................................................2
4.
OIL FEED LINE ....................................................................................................................2
5.
FUEL MANAGEMENT UNIT ................................................................................................3
5.1
FUEL MANAGEMENT UNIT RECALIBRATION ...................................................................4
6.
T-REX FUEL PUMP (High Output and Cobra Systems Only) ..............................................5
7.
MAIN BRACKET ASSEMBLY ...............................................................................................8
8.
SMOG PUMP HOSES ..........................................................................................................9
9.
RADIATOR HOSE ................................................................................................................10
10.
ACCESSORY BELT TENSIONER MOUNTING BRACKET .................................................10
11.
SUPERCHARGER MOUNTING ...........................................................................................11
12.
SUPERCHARGER DRIVE BELT ..........................................................................................11
13.
AIR FILTER ASSEMBLY ......................................................................................................13
14.
IGNITION/BOOST CONTROL INSTALLATION ....................................................................13
15.
IGNITION/BOOST CONTROL UNIT OPERATION ..............................................................14
16.
VORTECH BYPASS VALVE (High Output and Cobra Systems Only) ................................15
17.
FINAL CHECK ......................................................................................................................16
