User Manual
Software Version 2.7
© 2013 SurgeX / Electronic Systems Protection, Inc. / Technical Support: 1-800-645-9721 / surgex.com Page 5
2. PC Setup and Driver Installation:
Data interface cable model XG-PCS-IC-1 (optional)
Please Note:
The MULTIPAK may be accessed by a PC while connected to AC power and equipment or while
disconnected from AC power and equipment.
If accessed by a PC while connected to AC power: For best protection, it is recommended that the
power cord of the computer is plugged into an available receptacle on the MULTIPAK.
Connecting the MULTIPAK to a PC allows for the availability of the
following features:
• Import data stored in the MULTIPAK’s device memory
• Import data from a stored data file
• Export data to a data file
• Export data to a report in PDF format
• Set over and under voltage shutdown thresholds
• Clear device memory
• Real-time AC voltmeter
• Enhanced Logging Mode
Equipment required for PC communication:
• MULTIPAK
• MULTIPAK Data Interface Cable (optional)
• MULTIPAK Diagnostic Software (Revision 2.7)
• PC running Windows 2000 or later with a CD-ROM and USB port and
a minimum screen resolution of 1024 x 768
CAUTION – Do not install this device if there
is not at least 10 meters (30 feet) or more of
wire between the electrical outlet and the
electrical service panel.
La PRUDENCE - n’installe pas cet artifice s’il
n’y a pas au moins 10 mèters (30pieds) ou
plus de fil entre l’issue èlectrique et le comitè
de service èlectrique.
