4. Menu Items
a. File Menu:
i. Import Data from XG: Manually import data stored in the MULTIPAK’s internal memory.
ii. Import Data from File: Import data from a previously stored data file. Does not require
MULTIPAK connectivity.
iii. Export Data to File: Exports the currently displayed data to a data file, which can be
imported for future viewing. The data file may be saved as text (.txt) or comma-separated
(.csv, suitable for viewing in MS Excel). Including the Enhanced Logging Mode data is
optional.
iv. Save Report: Saves a summary report of the currently displayed data in PDF format.
v. Save Image: Saves a screenshot of the program as an image (.bmp) file.
vi. Print: Prints a screenshot of the program.
vii. Exit: Terminates connectivity with any connected MULTIPAK and exits the program.
b. Setup Menu:
i. COM Port: Selects which COM port the program should connect through. The COM port
selection is saved to a configuration file and does not need to be chosen again the next
time the program is run (unless a new MULTIPAK Data Interface Cable is used).
ii. Logging Interval: Allows for the selection of the logging time interval between acquired line
voltage data points when using the Enhanced Logging Mode feature. The logging time
interval selections available are: 1 second, 2 seconds, 4 seconds, 10 seconds, and 30
seconds. When the line voltage is changing rapidly, additional data points will be recorded,
regardless of the time interval selection.
iii. Actions: Allows for the selection of which new event(s) will result in the sending of an email.
This feature is only available when the MULTIPAK is connected to a PC with an Internet
connection and the MULTIPAK software running.
