II. Installation
The Axess Setup and Control Utility is distributed as an installation file
Axess_SCU_Setup_127.exe. This file can be also downloaded from SurgeX at
Use of the Axess Setup and Control Utility Version Q110630G.127 requires Axess firmware
Q110630.286 or higher.
SCU Program Screen
The SCU Program screen is divided into two
sections. The left column is a list select box for
all Axess units identified by the system. Axess
units can be automatically identified by the
Discover function, or manually added using the
Add Axess button.
The right side of the screen contains the
Operations Tab Pages. It has three functions,
denoted by tabs on the top of the column:
Connect
Upload, Download, Login and Reboot
Control
Operate Outlets
Setup
Manage Configuration
Select List Box
The Select List Box is located on the left side of the
application. It is provided as a short cut to all of the
identified Axess units. The list box can be
automatically populated by clicking File/Discover or
by right-clicking in the box area and choosing
Discover. The newly discovered Axess units will be
highlighted in light blue.
