InfoStation Installation Guide - Rev. C01 StorCase Technology, Inc.
Installation 3
Figure 2: Drive Installation
Inserting a Drive into the Chassis
NOTE: A new drive carrier can be inserted into an empty bay at anytime. However, the
drive will not be ready for access until the following procedure is followed.
1. Press and hold the Insert/Remove button in until the Drive Ready LED starts to flash
(approximately 3 seconds).
2. Drive is ready to be accessed when the Drive Ready LED glows instead of flashes.
Drive
(Not Included)
InfoStation
Drive Carrier
#6-32 Phillips Head
Mounting Screw
(4 total)
IFS_18
