Figure 13: removing the module option cover plate – StorCase Technology 9-Bay 4U SCSI Ultra160 User Manual
Page 20
InfoStation Installation Guide - Rev. C01
StorCase Technology, Inc.
Installation
15
Figure 13: Removing the Module Option Cover Plate
InfoStation
Chassis
(Rear)
Module Option
Cover Plate
IFS_43
#6-32 Phillips
Head Screw
(3 per Plate)
#6-32 Phillips
Head Screw
(1 Place)
IFS_44
Save this
Section!
Module Option
Cover Plate
Figure 14: Disassembling the Module Option Cover Plate
